You can find a metal seated ball valve in hard industrial places. The valve has a tough body made from stainless steel, carbon steel, or nickel-based alloys. It works with a quarter-turn movement, so you can open or close it fast. The metal to metal seating between the ball and seat stops leaks and resists scratching. This design works well in very hot or cold places and with strong chemicals. A metal seated ball valve is special because it keeps sealing tight when softer seats might not work.

Key Takeaways

• Metal seated ball valves use strong materials like Stellite and tungsten carbide. These materials make the valves last longer and resist damage in hard places.

• The quarter-turn operation lets you open or close the valve quickly. This feature helps you control things fast in factories.

• Metal-to-metal sealing technology gives a tight seal when there is high pressure or heat. This design stops leaks even in rough conditions.

• Pick metal seated ball valves for jobs with steam, rough fluids, or very hot or cold temperatures. They work better than soft seated valves in these cases.

• TANGGONG VALVE products follow strict rules for the industry. This makes sure you get good and dependable valves for your factory.

Metal Seated Ball Valve Basics

Construction & Materials

Metal seated ball valves are made with very strong materials. Both the ball and the seat use tough metals. These valves often have alloys like Stellite, tungsten carbide, or chrome carbide. Each alloy helps the valve in a special way. Stellite does not rust or wear out easily. Tungsten carbide is great for places with lots of scratching, like in mining. Chrome carbide stays hard even when it gets really hot. You can see the main materials and what they do in the table below:

The body of these valves is usually stainless steel or another strong metal. This makes the valve able to handle high pressure, heat, and strong chemicals. Metal seated ball valves last longer than soft seat valves. They are more durable and work better in tough places. You can trust them where other valves might break.

Working Principle

You use a simple quarter-turn to work a metal seated ball valve. When you turn the handle 90 degrees, the ball inside moves. If the hole in the ball matches the pipe, fluid flows through. This means the valve is open. If you turn the ball so the solid part blocks the pipe, the valve closes. This stops the fluid from moving. The quick turn lets you start or stop flow fast. This is important in many factories.

The design lets fluid move smoothly with little blockage. You get good flow and a tight seal. The quarter-turn also means you can act fast in emergencies or when you need quick control.

Sealing Technology

Sealing is the most important part of these valves. Metal seated ball valves use a metal-to-metal seal between the ball and the seat. This gives a strong seal, even with high pressure or heat. The seats often have springs or use pressure to stay tight. This keeps the ball and seat together, even if the valve gets hot or shakes.

You can trust these valves to seal well in tough places. Here are some reasons why the seal works so well:

• The metal-to-metal seal stays tight, even under stress.

• Spring-loaded seats keep the seal strong during heat or shaking.

• The design handles high pressure and heat without losing the seal.

• The valve does not rust or wear out fast, so the seal lasts.

• You get a good seal where soft seats would not work.

Metal seated ball valves are very good at stopping leaks. They work well where you need to keep fluids in, even in hard conditions. The sealing design means you get long use and less fixing. You can count on these valves to keep your system safe and working well.

Features & Benefits of Metal Seated Ball Valves

Durability & Performance

Metal seated ball valves are made to last. They use tough materials like Stellite, tungsten carbide, and chrome carbide. These materials help the valve stay strong against wear, heat, and impact. You can see how each material works in the table below:

These valves work well where other valves break. You can use them in places with lots of erosion. They keep sealing tight even in tough spots. Metal seated ball valves can reach Class VI shutoff. If you take care of them, they last longer and leak less. You save money because they need less fixing. The table below shows how they compare to soft seat valves:

High Temperature & Pressure Resistance

Metal seated ball valves can handle heat and pressure. They keep sealing strong when temperatures go above 450ºF. They work at Class 900 pressure or higher.

The special metals do not melt or get weak when hot. The seal stays tight, so leaks are not a problem. You can trust these valves to keep flow safe and steady, even in harsh places.

TANGGONG VALVE Ball Valve Series Advantages

TANGGONG VALVE gives you more than just a strong valve. Their valves meet top industry standards. TANGGONG ball valves follow rules like ASME B16.34, ISO 15848, API 6D, API 607, and ASTM standards. These rules make sure the valves can handle heat, pressure, and fire.

TANGGONG uses strong metals for the ball and seat. You get a good seal and smooth flow. The design lets you control flow fast with a quarter-turn. You can use these valves in tough places like oil and gas, power plants, and chemical factories. The sealing keeps your system safe and cuts downtime. You get a valve that works hard and lasts a long time.

Soft Seat vs. Metal Seated Ball Valves

Material Differences

Soft seated valves and metal seated ball valves use different materials. Soft seated valves have PTFE seats. PTFE makes a tight seal for clean water or gas. PTFE does not react with most chemicals. It works well with many fluids. But PTFE cannot handle high heat or dirty fluids. Metal seated ball valves use strong alloys like Stellite or tungsten carbide. These metals let the valve work in hot, high-pressure, or dirty places. You need a metal seated ball valve for sand, slurry, or very hot fluids.

• Soft seated valves seal well for clean and gentle jobs.

• Metal seated ball valves are best for tough, hot, or dirty jobs.

• PTFE seats resist chemicals, but metal seats handle rough fluids.

Performance Comparison

You may wonder how these valves work. Soft seated valves give almost no leaks. They work well at low or medium pressure and temperature. Metal seated ball valves seal tightly, but sometimes a tiny leak can happen. This is because metal touches metal. Still, metal seats keep sealing when things get hot or rough. Metal seats can handle heat up to 650°C and high pressure. Soft seated valves may wear out fast with sand or grit.

Application Suitability

Pick soft seated valves for water, food, or clean gas. These valves seal best in gentle places. For power plants, oil and gas, or chemical jobs, use a metal seated ball valve. It keeps sealing when fluids are hot, dirty, or under high pressure. Metal seats stay strong and keep their shape at high heat. They work where soft seats would break. TANGGONG VALVE has both types, so you can choose what you need.

• Metal seated ball valves work in power, oil and gas, and chemical plants.

• Soft seated valves fit water, food, and HVAC systems.

• Metal seats last longer in tough places and need less fixing.

Comparison Table

Tip: If you need a valve for tough jobs, pick a metal seated ball valve from TANGGONG VALVE. You get strong sealing, long life, and safe flow even in hard places.

Applications of Metal Seated Ball Valves

Industry Uses

Metal seated ball valves are used in many tough places. They work well when heat, pressure, or rough materials can break other valves. Here are some places where you might see them:

• Thermal power plants use them for steam and ash. The valves handle hot steam and gritty ash. They keep sealing even when things get rough.

• Petrochemical and refining plants use them for moving catalysts and harsh fluids. The strong metals help the valve stay tight and keep working.

• Mining and mineral plants use them for abrasive slurries. The hard seats stop scratching and keep the seal strong.

• Pulp and paper factories use them for mixtures with fibers and grit. The valve keeps sealing even when fibers try to block it.

• Chemical reactors and gas systems use them for hot gases and tough jobs.

You can see how these valves help different industries in the table below:

When to Choose TANGGONG VALVE Ball Valve Series

Pick TANGGONG VALVE ball valves when you need something strong. TANGGONG VALVE uses special metals like stainless steel, duplex steel, and Inconel. These metals help the valve last longer in harsh places like marine and power plants. The valves give you tight shut-off and low pressure drop. This means your system works safely and smoothly.

TANGGONG VALVE ball valves meet important certifications like API 6D, CE, and ISO 9001:2015. These show you can trust the valve’s quality and safety. You also get good technical help and custom solutions for your needs.

Tip: If you need a metal seated ball valve for heat, pressure, or rough jobs, TANGGONG VALVE gives you strong sealing and reliability.

You know metal seated ball valves use strong metals for hard jobs. These valves seal well and last a long time. TANGGONG VALVE ball valves follow strict rules and work in tough places. When picking a valve, check these important things:

Think about the total cost, not just the price. The best valve saves money and keeps your system safe.

FAQ

What makes a metal seated ball valve different from a soft seated valve?

You get a metal-to-metal seal with a metal seated ball valve. This seal handles high heat, pressure, and rough fluids. Soft seated valves use plastic seats. These work best with clean fluids and lower temperatures.

Can you use a metal seated ball valve for steam or abrasive fluids?

Yes, you can. Metal seated ball valves work well with steam, slurries, and abrasive fluids. The hard metal seats resist scratching and wear. You get a longer-lasting seal in tough jobs.

How do you choose the right TANGGONG VALVE ball valve?

Check your fluid type, temperature, and pressure. Pick the right size and material. TANGGONG VALVE offers expert help. You can contact their team for advice.

What certifications do TANGGONG VALVE ball valves have?

TANGGONG VALVE ball valves meet ISO 9001:2015, API 6D, API 607, CE, and TUV standards. You can trust their quality and safety for your project.
